Specifications

Acoustic & Electrical Specifications

Gain Range

60dB (with firmware version 1.3.1)

Bit Depth

24-Bit

Sample Rates

44.1kHz 48kHz 88.2kHz 96kHz

48V Phantom Power

Yes

Simultaneous I/O

1 x 2

Number of Preamps

1

Direct Monitor

Yes

Bus Powered

Yes

OS Requirements

Mac OS10.10 or later Windows 7 or later

Power

USB bus-powered

Mechanical Specifications

Form Factor

Desktop

Analog Inputs

1 x Neutrik XLR-1/4" combo

Analog Outputs

2 x 1/4" speaker outputs (impedance balanced) 1 x 1/4" headphone output

USB Connectors

1 x USB-C

Depth

100mm total (with knobs), Chassis: 88mm

Width

124mm

Height

38mm

Weight

1lb 3.7oz or 560g
