Top grade AK4490 D/A chip (32-bit PCM 768kHz / DSD256) •
6 Inputs: 1x USB, 3x optical (TOSlink®), 2x coax (S/PDIF) •
Up to 32bit/768kHz asynchronous USB (XMOS technology) •
DSD64, DSD128 & DSD256 (DSD over PCM) •
Audio Class 2 (USB 2.0 High Speed) driver for Windows included •
Up to 24bit/192kHz for optical & coax inputs •
5 selectable digital filter characteristics •
3 selectable sound modes •
High-end ultra low phase oscillator with superior noise rejection •
RCA line level solid-state analogue output stage •
Ultra linear & ultra low noise circuitry •
Separate power supplies for every stage with advanced filter technology •
Upgradeable with optional linear power supply Power Box DS2 Sources •
Full metal casing in silver or black •
Optional with wooden side panels (rosenut, walnut, eucalyptus)
| D/A-converter |
AK4490 32-bit PCM 768kHz / DSD256 |
| Sampling rate converter |
AK4137EQ upsampling to 768kHz |
| Sampling rates |
32/44,1/48/88,2/96/176,2/192/352,8/384/768 kHz |
| DSD support |
DSD64, DSD128 and DSD256 |
| Filter settings |
5 different selectable on front |
| |
| Frequency response |
20Hz - 50kHz (+0/-1dB) |
| Analogue out |
RCA/Cinch |
| Output voltage |
2,2 Veff (switchable +6dB gain gives 4,4 Veff ) |
| THD |
0,00085% solid state out |
| Crosstalk |
-117dB (10kHz@0dB) |
| Signal to noise ratio |
113dB (20 - 20.000 kHz) |
| |
| Power consumption |
<1 watt standby, 600mA max |
| Outboard Power supply |
18V/1000mA DC (included) |
| Dimensions W x H x D |
206 x 72 x 200 (220mm with sockets) |
| Weight |
1010g without power supply |
