| Ισχύς εξόδου |
2500 W |
| Drivers |
Low-Frequency: 12.0” (305 mm) driver, 2.5” (63 mm) high-temperature voice coil. High-Frequency: 1.0” (25 mm) exit ceramic driver with 1.4” (35 mm) coil |
| Συχνότητα Crossover |
2 kHz |
| Maximum SPL |
131 dB (peak) dB-SPL @ 1 m |
| Απόκριση συχνότητας |
53 Hz – 20 kHz (+/-3 dB) |
| Εύρος Συχνοτήτων |
44 Hz – 20 kHz (-10 dB) |
| Horn Coverage |
90° horizontal x 60° vertical (nominal) |
| Συνδέσεις |
(2) XLR+1/4” (6.35 mm) TRS combo inputs (Balanced)
(1) XLR output (Link)
(1) IEC power cable input |
| Αντίσταση εισόδου |
Line: 10 KΩ balanced, 20 KΩ unbalanced |
| Gain/Volume Control Range |
-? to 0 dB, +4 dBu nominal, +10 dBu for max output |
| HPF Switch |
100 Hz |
| Bluetooth |
Version: 5.0
Profile: A2DP, AVRCP
Codec: SBC
Range: up to 100 feet (30.5m|) |
| Power |
Connection: IEC
Input Voltage: 100-120V, 50/60 Hz; 220-240V, 50/60 Hz Consumption: 1100W
Fuse: T15AL AC250V; 220-240V T6.3AL AC250V |
| Προστασία |
Electronic clip, thermal, and transducer overdrive protection |
| Τοποθέτηση/Εγκατάσταση |
Standard 36 mm pole socket |
| Θερμοκρασία λειτουργίας |
14°F to 113°F (-10°C to 45°C) |
| Διαστάσεις (πλάτος x βάθος x ύψος) |
13.9” x 13.8” x 23.9” 351 mm x 354 mm x 607 mm |
| Βάρος |
34.7 lbs. / 15.7 kg |
