SMP (Series Multi-Stage Protection Plus)

EVS (Extreme Voltage Shutdown)

LiFT (Linear Filtering Technology)

Surge Protection

Noise Filtration

LiFT offers AC power filtering to ensure clean power for unequalled audio & video clarity.

Input: 10A

Output: 10 x 10A rear panel

1 x 10A front panel

Spike protection mode: SMP, Line to Neutral, Zero ground leakage

Let through voltage: 376V peak/ 266V RMS @ 3000A

Noise attenuation (Transverse Mode): 10dB @ 10kHz, 40dB @ 100kHz, 50dB @ 500kHz

Voltage Protection

Advanced EVS circuitry detects dangerous voltage irregularities and safely powers down itself and

connected equipment in unsafe conditions.

Pull-out Lights

Dual smooth track retractable LED lights illuminate equipment in rack.

Diagnostic Lights, LED status indicators warn you when voltage is outside of nominal range or when

protection has been compromised.

Isolated Banks, Isolated outlet banks minimize inter-component interference and noise

contamination.

Rear panel BNC connector powers any standard gooseneck lamp for rear rack illumination.

Rack mount. Dimensions (W x H x D): 482.6 x 44.45 x 266.7 mm. Weight: 6 kg
