Solid-state SD/USB audio recorder/player •Καταγράφει αρχεία WAV και Mp3 ταυτόχρονα σε SD και USB •Απλό και εύκολο στη χρήση
Σύστημα:
Solid-state SD/USB audio recorder/player
Compatible Media (FAT16, FAT32)
USB Device (mass storage class)
SD/SDHC
SDXC
Υποστηριζόμενες μορφές αρχείων
MP3
Sampling frequency: 44.1 kHz
Bit rate: 192, 256 kbps (recording); 64 - 320 kbps and VBR (playback)
Format: MPEG1 Audio Layer 3
File extension: .mp3
WAV
Sampling frequency: 44.1, 48 kHz
Bit depth: 16-bit (44.1 kHz), 24-bit (48 kHz)
Format: Waveform Audio File Format
File extension: .wav
Number of Channels: 2 channels / stereo
Audio Frequency Range: 10 - 20 kHz (± 1.0dB recording, ± 0.8 dB playback)
Signal-to-Noise Ratio
Recording: > 95 dB (1 kHz, 0dB A-weighted)
Playback: > 95 dB (1 kHz, 0dB A-weighted)
Διαχωρισμός καναλιών
Recording: > 80 dB (1 kHz, 0dB A-weighted)
Playback: > 90 dB (1 kHz, 0dB A-weighted)
Wow and Flutter: < 0.001 %
Distortion
Recording: < 0.008 %
Playback: < 0.006 %
Total Harmonic Distortion: < 0.01% (1 kHz, 0dB A-weighted)
Είσοδοι
Balanced XLR
Nominal level: +4 dBu ± 1 dBu
Minimum level: - 40 dBu
Maximum level: 20 dBu ± 1 dBu
Input impedance: 18 ka„¦
Εξόδους
Balanced XLR
Nominal level: +4dBu ± 1 dBu
Maximum output level: +20 dBu ± 1 dBu
Output impedance: 600 a„¦ ± 10%
Unbalanced RCA
Nominal level: -10 dBV ± 2 dBV
Minimum output level: 6 dBV ± 2 dBV
Συνδέσεις
(2) XLR outputs
(1) 1/4" (6.35mm) headphone output
(1) RCA stereo output pair
(2) XLR inputs
(1) RCA stereo input pair
(1) USB port
(1) SD card slot
(1) IEC AC power input
Power
Connection: IEC
Input Voltage: 100 - 240 V~, 50/60 Hz
Διαστάσεις (width x depth x height): 484 x 277 x 44mm
Βάρος: 3 kg
