Speaker type:
Center speaker,Front,Rear,Surround
Recommended placements:
On-Wall
Frequency range+/- 3 dB [Hz] min:
45
Frequency range+/- 3 dB [Hz] max:
34.000
Sensitivity (2,83 V/1 m) [dB]:
86.0
Nominal impedance [ohms]:
6
Maximum SPL [dB]:
106
Recommended amp. power [Watts] min:
20
Recommended amp. power [Watts] max:
120
Crossover frequencies:
3.000/12.000
Hybrid tweeter module, Super high freq. driver, Quantity:
1 x 17 x 45 mm
Hybrid tweeter module, Super high freq. driver, Diaphragm type:
Ribbon
High frequency driver, Quantity:
1 x 28 mm
High frequency driver, Diaphragm type:
Soft Textile Dome
Low frequency driver, Quantity:
1 x 5"
Low frequency driver, Diaphragm type:
Wood Fibre Cone
Enclosure type:
Bass Reflex
Connection input(s):
Single Wire
Magnetic shielding:
No
Loudspeaker dimensions including base and grille (HxWxD) [mm]:
660 x 165 x 150
Loudspeaker weight including base and grille [kg]:
6.2
Accessories included:
Manual,Rubber Pads
