| Eίσοδος |
|
| Προενισχυτές |
8x MIDAS-designed |
| Τύπος |
XLR / TRS combo connector (Mic/Line/Instrument),2front /6rear |
| Input level attenuation |
8 x pad switch |
| Απόκριση συχνότητας |
10 Hz – 85kHz (+0/-3dB) /direct monitor |
| Αντίσταση |
Mic in:3kΩ / Instrument in:1 MΩ |
| Max. input level |
Mic:11dBu/Line:11dBu/ Instrument:18dBu |
| Phantom power |
+48 V switchableinputs1-4 and5-8 |
| ΄Eξοδος |
|
| Τύπος |
8x ? " TRS, lineoutputs 2x ? " TRS, main outputs 2x ? " TRSstereo, headphoneoutputs |
| Απόκριση συχνότητας |
10 Hz – 85kHz (+0/-3dB) /direct monitor |
| Max.output level |
+16dBu lineoutputs +16dBu main outputs +21.5dBu headphoneoutputs |
| Δεδομένα συστήματος |
|
| Δυναμικό εύρος |
106dB, A-weighted |
| Απόκριση συχνότητας |
10 Hz – 40kHz (+0/-3dB) @ 96kHz samplingrate |
| Digital Audio I/O |
|
| Τύπος |
Coaxial: RCA – 1 In,1 Out Optical: TOSLINK – 1 In,1 Out |
| Υποστηριζόμενα formats |
ADAT,S/PDIF,S/MUX |
| MIDI I/O |
|
| Τύπος |
Coaxial: RCA – 1 In,1 Out Optical: TOSLINK – 1 In,1 Out |
| Υποστηριζόμενα formats |
ADAT,S/PDIF,S/MUX |
| MIDI I/O |
|
| Τύπος |
5-pin DIN,1in /1out |
| Monitoring |
|
| Direct monitor control |
Mixcontrol (inputs/playback1-2) Sourceselect (analoginputs1-2/1-8) Stereo/Monoselect |
| Main L/R control |
OutputLevel 1/L – 2/R control,dim and muteswitch |
| Headphones DJ cueing |
Monitor switches (monitor mix1-2/playbackout3-4) |
| Digital Processing |
|
| Converter resolution |
24-bit |
| Υποστηριζόμενα sample rates |
44.1, 48,88.2,96kHz |
| Digital I/O Routing |
|
| S/PDIF selected(OPT I/O switch out) |
RCA In = off Optical In = S/PDIF (ch.9-10) RCA Out + Optical Out = S/PDIF (ch.11-12) |
| ADAT selected(OPT I/O switch in) |
RCA In = S/PDIF (ch.9-10) Optical In @ 96/88.2kHz = S/MUX (ch.11-14) Optical In @ 48/ 44.1kHz = ADAT (ch.11-18) RCA Out = S/PDIF (ch.11-12) Optical Out @ 96/88.2kHz = S/MUX (ch.13-16) Optical Out @ 48/ 44.1kHz = ADAT (ch.13-20) |
| Computer Bus Connectivity |
|
| Τύπος |
USB 2.0, type B |
| Υποστήριξη λογισμικού |
|
| Λειτουργικά συστήματα |
Fully compatible with Windows XP or higher Fully compatible with Mac OS10.9(Mavericks)or higher Forolder OS X versions, the following restrictions apply: 10.8 (Mountain Lion) + 10.7 (Lion): After changing the “OPT I/O” mode with thefrontpanel switch,you must refresh the OS X Audio-Midi-Setup window to get the correct I/O channel numbers indicated. 10.6 (Snow Leopard): The UMC1820 can only be used in S/PDIF mode(“OPT I/O” switch notpressedin). ADAT operation is NOT supportedbythis OS X version. 10.5 + earlier versions are not supported |
| Drivers |
Mac: Nodriver required(CoreAudio/CoreMIDI compliant) Windows:2driversareavailable: onedriver forWindows XPorWindows Vista onedriver forWindows 7 to10 Downloadthecorrectdriver foryour system from behringer.com |
| Power Supply / Voltage |
|
| Voltage |
12 V DC(from supplied AC/DCadapter) |
| Power consumption |
20W |
| Διαστάσεις / Βάρος |
|
| Διαστάσεις (Υ xΠx Β) |
46x 483x130 mm |
| Βάρος |
1.8kg |
