| Είσοδοι μικροφώνου |
|
| Τύπος |
9 x XLR, electronically balanced discrete input circuit, channels 1 - 12 |
| Mic E.I.N. (20 Hz to 20 kHz) |
|
| @ 0 Ω αντίσταση πηγής |
-108 dB / -110 dB A-weighted |
| @ 50 Ω αντίσταση πηγής |
-108 dB / -110 dB A-weighted |
| @ 150 Ω αντίσταση πηγής |
-106 dB / -107 dB A-weighted |
| Απόκριση συχνότητας (-1 dB) |
<20 Hz to 22 kHz (-1 dB) |
| Απόκριση συχνότητας (-3 dB) |
<20 Hz to 35 kHz (-3 dB) |
| Μέγιστo level εισόδου |
+13 dBu with PAD |
| Αντίσταση |
1.5 kΩ, balanced |
| Signal-to-noise ratio |
98 dB / 100 dB A-weighted (-15 dBu In @ +35 dB gain) |
| Distortion (THD+N) |
0.002%, A-weighted |
| Pad |
-25 dB, channels 1 - 6 |
| Phantom power |
+48 V, switchable |
| Hi-Z / Line Inputs |
|
| Τύπος |
4 x 1/4" TRS, balanced, channels 1 - 4 |
| Αντίσταση |
1.8 MΩ balanced, 1 MΩ unbalanced |
| Μέγιστo level εισόδου |
+22 dBu |
| Wireless Input |
|
| USB dongle (not included) |
USB socket accepts signals from max. 2 BEHRINGER ULM microphones |
| Signal indicator LED |
2 (green) |
| Mono Line Inputs |
|
| Τύπος |
2 x 1/4" TRS, balanced, channels 5 and 6 |
| Αντίσταση |
20 kΩ balanced, 10 kΩ unbalanced |
| Μέγιστo level εισόδου |
+22 dBu |
| Stereo Line Inputs |
|
| Τύπος |
6 x 1/4" TRS connector, balanced channels 7 - 12 |
| Αντίσταση |
20 kΩ balanced, 10 kΩ unbalanced |
| Μέγιστo level εισόδου |
+22 dBu |
| 2-Track / Line In |
|
| Τύπος |
6 x 1/4" TRS connector, balanced channels 7 - 12 |
| Αντίσταση |
20 kΩ balanced, 10 kΩ unbalanced |
| Μέγιστo level εισόδου |
+22 dBu |
| 2-Track / Line In |
|
| Type |
6 x 1/4" TRS connector, balanced channels 7 - 12 |
| Αντίσταση |
20 kΩ balanced, 10 kΩ unbalanced |
| Μέγιστo level εισόδου |
+22 dBu |
| 2-Track / Line In |
|
| Τύπος |
2 x RCA, unbalanced, channels 13 and 14 |
| Αντίσταση |
20 kΩ unbalanced |
| Gain range |
-? dB to +20 dB |
| Μέγιστo level εισόδου |
+22 dBu |
| Channel EQ |
|
| Channel EQ Low |
+-15 dB @ 60 Hz |
| Mid |
+-15 dB @ 700 Hz |
| High |
+-15 dB @ 6 kHz |
| Aux In |
|
| Τύπος |
1/8" TRS connector, unbalanced |
| Αντίσταση |
10 kΩ |
| Gain range |
-? dB to +20 dB |
| 2-Track / Line Out |
|
| Τύπος |
2 x RCA, unbalanced |
| Αντίσταση |
2.4 kΩ |
| Μέγιστo level εξόδου |
+9 dBu |
| Graphic Equalizers |
|
| Τύπος |
analog 9-band equalizer |
| Frequency range |
20 Hz to 20 kHz in 9 1-octave bands (ISO frequencies) |
| Bandwidth |
1 octave |
| Control range |
+-12 dB |
| Low Cut |
|
| Τύπος |
18 dB/oct., Butterworth, channels 1 – 6 |
| Συχνότητα |
100 Hz |
| Main Mix System Data (Noise) |
|
| Main mix @ -?, channel fader @ -? |
-59 dBu / -59 dBu A-weighted |
| Main mix @ 0 dB, channel fader @ -? |
-56 dBu / -56 dBu A-weighted |
| Main mix @ 0 dB, channel fader @ 0 dB |
-56 dBu / -56 dBu A-weighted |
| Power Amp Specifications |
|
| Μέγιστo level εξόδου |
|
| Both channels driven |
|
| 8 Ω per channel |
500 W* |
| 4 Ω per channel |
1000 W* |
| Bridged mode |
|
| 8 Ω |
2000 W* |
| Loudspeaker Connections |
|
| Connectors |
2 x professional twist-locking speaker connectors |
| Load Impedance |
|
| Left / monitor |
Min. 4 Ω |
| Right / mono |
Min. 4 Ω |
| Bridge |
Min. 8 Ω |
| Power Supply / Voltage (Fuses) |
|
| UK / Australia / Europe/Korea / China |
220-240 V~, 50/60 Hz (T 5 A H 250 V) |
| Power consumption @ 4 Ω, 1/8 rated power |
180 W |
| Mains connection |
Standard IEC receptacle |
| Διαστάσεις / Βάρος |
|
| Διαστάσεις (Υ x Π x Β) |
276 x 455 x 250 mm |
| Βάρος |
9.0 kg |
