B215D |
B212D |
B210D |
B208D |
| Έξοδος ισχύος ενισχυτή |
|
|
|
|
| Εύρος χαμηλής συχνότητας |
|
|
|
|
| RMS Power |
280 W @ 8 Ω |
280 W @ 8 Ω |
135 W @ 8 Ω |
135 W @ 8 Ω |
| Peak Power |
450 W @ 8 Ω |
450 W @ 8 Ω |
160 W @ 8 Ω |
160 W @ 8 Ω |
| Εύρος υψηλών συχνοτήτων |
|
|
|
|
| RMS Power |
65 W @ 8 Ω |
65 W @ 8 Ω |
38 W @ 8 Ω |
38 W @ 8 Ω |
| Peak Power |
100 W @ 8 Ω |
100 W @ 8 Ω |
42 W @ 8 Ω |
42 W @ 8 Ω |
| Μέγεθος ηχείου |
|
|
|
|
| Μέγεθος |
15" |
12" |
10" / 25 cm |
8" / 20 cm |
| Είσοδοι ήχου |
|
|
|
|
| XLR (Servo-Balanced) |
|
|
|
|
| Ευαισθησία |
-40 dBu to +4 dBu |
-40 dBu to +4 dBu |
-40 dBu to +4 dBu |
-40 dBu to +4 dBu |
| Αντίσταση εισόδου |
20 kΩ |
20 kΩ |
20 kΩ |
20 kΩ |
| |
|
|
|
|
| 1/4" TRS Jack (Servo-Balanced) |
|
|
|
|
| Ευαισθησία |
-40 dBu to +4 dBu |
-40 dBu to +4 dBu |
-40 dBu to +4 dBu |
-40 dBu to +4 dBu |
| Αντίσταση εισόδου |
20 kΩ |
20 kΩ |
20 kΩ |
20 kΩ |
| Level Control |
|
|
|
|
| Input Trim |
-? to + 30 dB |
-? to + 30 dB |
-? to + 30 dB |
-? to + 30 dB |
| Max. input level |
+22 dBu |
+22 dBu |
+22 dBu |
+22 dBu |
| Link |
|
|
|
|
| Σύνδεση |
XLR connector |
XLR connector |
XLR connector |
XLR connector |
| Loudspeaker System Data |
|
|
|
|
| Απόκριση συχνότητας |
65 Hz to 20 kHz |
65 Hz to 20 kHz |
65 Hz to 20 kHz |
65 Hz to 20 kHz |
| Crossover συχνότητα |
1.9 kHz |
2.4 kHz |
24 kHz |
24 kHz |
| Στάθμη ηχητικής πίεσης |
max. 126 dB SPL @ 1 m |
max. 126 dB SPL @ 1 m |
max. 126 dB SPL @ 1 m |
max. 126 dB SPL @ 1 m |
| Limiter |
Optical |
Optical |
Optical |
Optical |
| Dynamic Equalizer |
Processor-controlled |
Processor-controlled |
Processor-controlled |
Processor-controlled |
| Equalizer |
|
|
|
|
| HIGH |
12 kHz / +-15 dB |
12 kHz / +-15 dB |
12 kHz / +-15 dB |
12 kHz / +-15 dB |
| LOW |
80 Hz / +-15 dB |
80 Hz / +-15 dB |
80 Hz / +-15 dB |
80 Hz / +-15 dB |
| Παροχή ηλεκτρικού ρεύματος |
|
|
|
|
| Voltage (Fuses) |
|
|
|
|
| USA/Canada |
120 V, 60 Hz (T 6.3 A H 250 V) |
120 V, 60 Hz (T 6.3 A H 250 V) |
120 V, 60 Hz (T 4.0 A H 250 V) |
120 V, 60 Hz (T 4.0 A H 250 V) |
| UK/Australia |
240 V~, 50 Hz (T 3.15 A H 250 V) |
240 V~, 50 Hz (T 3.15 A H 250 V) |
240 V~, 50 Hz (T 2.0 A H 250 V) |
240 V~, 50 Hz (T 2.0 A H 250 V) |
| Europe |
230 V~, 50 Hz (T 3.15 A H 250 V) |
230 V~, 50 Hz (T 3.15 A H 250 V) |
230 V~, 50 Hz (T 2.0 A H 250 V) |
230 V~, 50 Hz (T 2.0 A H 250 V) |
| Κατανάλωση ενέργειας |
max. 600 Watts |
max. 600 Watts |
max. 300 Watts |
max. 300 Watts |
| Mains σύνδεση |
Standard IEC receptacle |
Standard IEC receptacle |
Standard IEC receptacleStandard IEC receptacle |
|
| Διαστάσεις & Βάρος |
|
|
|
|
| Διαστάσεις (Υ x Π x Β) |
approx. 27.2 x 17.3 x 13.2" approx. 690 x 440 x 335 mm |
approx. 21.7 x 13.6 x 10.6" approx. 550 x 345 x 270 mm |
approx. 18.34 x 11.50 x 9.61" approx. 466 x 292 x 244 mm |
approx. 14.72 x 9.8 x 8.1" approx. 374 x 249 x 205 mm |
| Βάρος |
45.2 lbs / 20.54 kg |
31.9 lbs / 14.5 kg |
19.18 lbs / 8.7 kg |
15 lbs / 6.8 kg |
